Hypertherm XPR300 User Manual

Installation
3
XPR300 Instruction Manual 809480 99
Connect the plasma power supply and gas connect console (Core, VWI, or OptiMix)
RS422
Power
Pilot
Arc
CNC
Discrete
Pilot Arc
Work
CAN
RS422
Negative
Power
V
RS422
Negative
Work
EtherCAT
Out
CAN
CNC Discrete
Coolant
Supply
(Green)
Coolant
Return
(Red)
+
-
+
-
EtherCAT
In
EtherCAT
Table 17 – Definitions of symbols on the label
inside the plasma power supply
CAN
Power
- Negative
+ Work
Pilot arc
Coolant supply
Coolant return
CAN
V

Hypertherm XPR300 Specifications

General

Cutting Current	300 A
Duty Cycle	100% at 300 A
Technology	X-Definition Plasma
Gas Supply	Oxygen, Nitrogen, Air
Cutting Capacity (Mild Steel)	38 mm (1.5 in)
Severance Capacity (Mild Steel)	75 mm (3 in)
Pierce Capacity (Mild Steel)	50 mm (2 in)
Input Voltage	200–480 V, 3-PH, 50/60 Hz
