STATus Subsystem

Also see

None

STATus:PRESet

Presets all Enable, PTR, and NTR registers.

Operation register Questionable

Preset setting

STAT:OPER:ENAB STAT:QUES:ENAB All defined bits are

disabled

STAT:OPER:NTR STAT:QUES:NTR All defined bits are

disabled

STAT:OPER:PTR STAT:QUES:PTR All defined bits are

disabled

Group

STATus

Syntax

STATus:PRESet

Arguments

None

Default Value

None

Returns

None

Example

Preset the Operation and Questionable registers: STATus:PRESet
