Industrial Sewing Machine SADE
114
(Example 2) In the case where neither automatic reverse feed stitching for start nor that
for end have been specified :
If the switch ❷ is pressed before starting
sewing, the automatic reverse feed stitching
for start (between A and B) will be carried out.
If the switch ❷ is pressed during sewing, the
automatic reverse feed stitching for end (be-
tween C and D) will be carried out.
❸ Needle lifting switch
When the switch is pressed, the needle moves from its lower-end stop position to its
upper-end stop position.
When raising the machine head which has been tilted, do not hold the opera-
tion switch to raise it.
❹ 2P switch
This is not used in SADE for stitch length changing.
In machine SADE stitch length is changed in program – see clause 7.1.2.13.
❺ Needle thread tension changeover switch
When the switch is pressed, the double tension function is selected to increase the
needle thread tension. (The lamp above the switch is lit up.)
❻ This is not used for the LU-2810-7.
7.10 Machine protection when is not in use
NOTE!
At the downtime, switch the machine off (close program and com-
puter, then switch the machine off) – you will avoid the risk of acci-
dental start by unauthorized persons.
At the longer downtime switch the machine off (as mentioned above) and remove the
power cord plug from the socket. Fold this cord and put it on the table.
Be sure to thoroughly clean the machine.
