Industrial Sewing Machine SADE
30
Table 1. continued
Parameter Unit Industrial Sewing Machine SADE
DELL screen, the touch panel
emission sound pressure
level*
dB (A) 83,0
*1 The speed setting according to the amount of the alternating vertical movement of the walking foot and presser
foot is automatically carried out.
* Equivalent continuous emission sound pressure level (L
pA) at the workstation: A-weighted value of 83.0 dB; (in-
cludes K
pA = 2.5 dB); according to ISO 10821- C.6.2 - ISO 11204 GR2 at 3,000 sti/min. - Sound power level (LWA); A-
weighted value of 88.5 dB; (includes K
WA = 2.5 dB); according to ISO 10821-C.6.2 - ISO 3744 GR2 at 3,000 sti/min.
3.3 Construction and operations
The industrial sewing machine SADE consists of (see fig. 3):
− sewing machine head (1),
− sewing machine stand (2) designed as a table with adjustable work table height,
− pedal switch (3),
− control box (4),
− control touch panel (5),
− stand for thread spools (6),
− printer (7),
− a set of laser sensors (8),
− card reader (9),
− barcode reader (10),
− electrical installation,
− pneumatic regulator (11).
The machine is powered from the mains current 1-phase 230 V / 50 Hz. The power of
sewing machine is 500 W, the total mass is 180 kg.
The machine stand is equipped in 4 wheels with brakes, that allows moving machine to
required workplace. The height of work table is adjustable to adjust the machine to the
operator's height and to ensure the most ergonomic posture at the standing workstation.
The stands for: thread spools, printer and control touch panel are also adjustable for the
ergonomic reasons.
Machine is equipped in a main switch to cut off power supply when machine is not work-
ing. A main switch is placed on a control box wall. Next to the main switch is backlit but-
ton, that is used to computer switching on.
The driver CP-18 to adjust the machine head is placed in a control box. Only an author-
ized and qualified person can set parameters on CP-18 driver.
