Industrial Sewing Machine SADE
52
Fig. 26. Placing thread cones
Like on all sewing machines the thread guide should be straight above the cone allow-
ing the thread to come off vertically. SADE uses sensors to sense the thread cone being
present at the cone stand and not only scanning the bar code.
NOTE!
The cones can only be read by the stationary
the cones once their presence is checked by the sensors.
5.5 Attaching and removing the bobbin
Switch of the sewing control motor first.
Place the bobbin width the “Main chamber” facing the bar codes upwards.
Fig. 27. Attaching and removing the bobbin
