134
ru.20
Output voltage
This is the actual phase to phase output voltage to the motor.
Units: Volts
The raw status of the input terminals. Each input is binary weighted according to the
table below. If an input is activated the value corresponding to the input is displayed.
If multiple inputs are activated the sum of the values is displayed. This parameter
includes software linked inputs.
Input Terminal Function Value
X2A.16 Enable 1
X2A.17 Reset 2
X2A.14 Up 4
X2A.15 Down 8
X2A.10 Option-Emerg. Pwr. 16
X2A.11 Leveling speed 32
X2A.12 High Level speed 64
X2A.13 High Speed 128
none Internal function 256
none Internal function 512
none Internal function 1024
none Internal function 2048
This is the processed status, after  lters, software switches etc. of the inputs. The
same weighting scheme applied as in parameter ru.21.
This is the state of the internal output conditions. Multiple active conditions results
in the sum of the values.
Condition Value
0 1
1 2
2 4
3 8
4 16
5 32
6 64
7 128
ru.21
Input terminal
state
Example: Input X2A.16 and
X2A.14 are active.
1 + 4 = 5
Other examples:
96 = Inspection speed
160 = Intermediate speed 1
192 = intermediate speed 2
224 = intermediate speed 3
+ 5 for up
+9 for down
ru.22
Input terminal
state
ru.23
Output terminal
state
Diagnostic Parameters
