83
Parameter Description - Basic Set Up
6.2 LF-Elevator Parameters
This value determines the type of speed selection and rotation
setting.
Value range: AbSPd = Absolute Analog Speed
d SPd = Digital Speed Selection
A tor = Analog Torque Control
A SPd = Analog Speed Control
SErSP = Serial Com. Speed Control
bnSPd = Binary Speed Selection
Default setting: bnSPd
Signal / operating mode
When LF.2 = A tor then: max. system speed is approximately 110% of
(LF.20)
When LF.2 = AbSPd or A SPd then: 0 ... ±10V = 0 ... ± max. system speed
(LF.20)
Value Control mode Direction Selection
Abs. Analog Spd. Control terminals X2A.14 &
AbSPd 0...+10V terminals X2A.15
X2A.1, X2A2
Digital Speed Control terminals X2A.14,
d SPd terminals X2A.10, X2A.11, X2A.15
X2A.12,X2A.13
Analog Torque Control terminal X2A.14,
A tor -10V...0... +10V terminals does not determine direction
X2A.1, X2A2, X2A.3, X2A4 used only for triggering the
start sequence
Analog Speed Control terminals X2A.14 &
A SPd -10V...0...+10V terminals X2A.15
do not determine
X2A.1, X2A2 direction. Used only for
triggering the start sequence
Digital Serial Speed Control
SErSP Serial communication Serial communication
16 bit signed speed value 16 bit control word
Binary Speed Control terminals X2A.14,
bnSPd terminals X2A.11, X2A.15
X2A.12, X2A.13
