138
All remaining ru parameters are not important for the function of the elevator drive
and therefore are not documented here.
i
ru.81
Active Motor
Power
Displays the motor temperature. This value is only valid when the motor has a KTY
thermal sensor installed and that sensor is connected to the T1/T2 terminals.
Units: °C
Display the value of the internal position counter.
Units: counts
This is the actual electrical power going to the motor. A negative value means power
being generated by the motor.
Units: kW
Displays the peak speed as measured by the motor encoder. Can be rest by pressing
the down arrow key or after power off.
Units: rpm
Only for Induction motors, displays the actual magnetizing current. The value will
drop as contract speed is reached because the ux controller is adjusting for eld
weakening.
Units: amps rms
ru.85
Peak Motor
Speed
ru.87
Magnetizing
Current
ru.46
Motor
temperature
ru.54
Position
counter
Advanced Parameters
