5. Initial Start-up

5.1 Selecting The Con guration

Before trying to operate the drive it is necessary to establish the correct mode

of operation. The F5 drive is capable of driving different types of motors both

open and closed loop. Therefore prior to operation, the type of motor and

mode of operation (open or closed loop) must be established.

Note: In most cases the elevator control manufacturer will make the

adjustment of the con guration and control mode, sections 6.1 and 6.2,

and therefore it is not necessary to make these adjustments in the  eld. In

this case simply verify parameter LF.4 matches the required con guration

number listed below.

The available motors and modes or con gurations are listed below. From this

list it is possible to select the correct con guration setting of the Drive.

Motor Open Closed Con guration

Type Loop Loop Display Code

Induction Geared - x ICLSd

Induction Gearless - x I9LSS

PM Synchronous Geared - x PCLSd

PM Synchronous Gearless - x P9LSS

With the con guration code noted, go to parameter US.10 on the keypad of the

drive and press “Function.” Select the con guration code indicated and press

“Enter.”

Once the con guration is selected, it is now necessary to load the con guration

 le. This adjusts the drive for the correct motor type and establishes the correct

internal settings.

To load the con guration go to parameter US.04, set the display to LoAd and

press enter. The display will show Pro9 and the con guration  le will be loaded.

The display will con rm whether the load was successful. If the display ultimately

changes to parameter LF.99 and shows noP, the load was successful. If the

 le is not completely loaded, the display will show bdPAS for bad operation and

will remain at parameter US.4. In this case power cycle the drive and try to load

the con guration again. Make sure that no inputs are active while trying to load

the con guration. LF.82 should read 0. If still unsuccessful there may be an

incompatibility between the operator and the drive. Contact the manufacturer

for further assistance.

After loading, the con guration can be veri ed through parameter LF.4. The

same con guration code as that selected in US.10 will be displayed in LF.4.

Also after a successful load US.4 will display PASS.

5.2 Loading The Con guration

Initial Start Up
