KEB COMBIVERT F5 User Manual

194
A.2 Customer Parameter Values
Para. Name Customer
Value
Unit
LF.02 Steering/Operating Mode
LF.03 Drive con guration
LF.04 Drive Mode
LF.05 Auto Reset
LF.08 Electronic Mtr Protection
LF.09
Electronic Mtr Protection
Current A
LF.10 Rated Motor Power hp
LF.11 Rated Motor Speed rpm
LF.12 Rated Motor Current A
LF.13 Rated Motor Frequency Hz
LF.14 Rated Motor Voltage V
Voltage Constant ke
LF.15 Power Factor -
LF.16 Field Weakening Speed rpm
LF.17 Rated Motor Torque lb ft
LF.18 Motor Resistance ohms
LF.19 Motor Inductance mH
LF.20 Contract Speed ft/min
LF.21
Traction Sheave
Diameter inches
LF.22 Gear Reduction Ratio -
LF.23 Roping Ratio -
LF.24 Load lb
LF.27 Encoder Pulse Number ppr
LF.28 Swap Encoder Channels -
LF.29 Sample rate for encoder mS
LF.30 Control Mode -
A.LF.31 KP Speed (accel) -
d.LF.31 KP Speed (decel) -
P.LF.31
KP Speed (Synth. Pre-
Torque) -
A.LF.32 KI Speed (accel) -
d.LF.32 KI Speed (decel) -
P.LF.32
KI Speed (Synth. Pre-
Torque) -
A.LF.33 KI Speed Offset (accel) -
Para. Name Customer
Value
Unit
0.LF.36 Maximum Torque lbft
1.LF.36 Max.Torq. (emergency) lbft
LF.37 Low Speed Torque Boast %
LF.38 Switching Frequency -
LF.41 Leveling Speed ft/min
LF.42 High Speed ft/min
LF.43 Inspection Speed ft/min
LF.44 High Leveling Speed ft/min
LF.45 Intermediate Speed 1 ft/min
LF.45 Intermediate Speed 2 ft/min
LF.45 Intermediate Speed 3 ft/min
0.LF.50 Start Jerk ft/s
3
0.LF.51 Acceleration ft/s
2
0.LF.52 Acceleration Jerk ft/s
3
0.LF.53 Deceleration Jerk ft/s
3
0.LF.54 Deceleration ft/s
2
0.LF.55 Approach Jerk ft/s
3
1.LF.50 Start Jerk ft/s
3
1.LF.51 Acceleration ft/s
2
1.LF.52 Acceleration Jerk ft/s
3
1.LF.53 Deceleration Jerk ft/s
3
1.LF.54 Deceleration ft/s
2
1.LF.55 Approach Jerk ft/s
3
2.LF.50 Start Jerk ft/s
3
2.LF.51 Acceleration ft/s
2
2.LF.52 Acceleration Jerk ft/s
3
2.LF.53 Deceleration Jerk ft/s
3
2.LF.54 Deceleration ft/s
2
2.LF.55 Approach Jerk ft/s
3
LF.56 Stop Jerk ft/s
3
LF.57 Speed Following Error
LF.58 Speed Difference %
LF.59 Following Error Timer sec
LF.61 Emergency Power Mode -
LF.67 External Pre-torque Gain -
