14-12 SCPI Reference Tables Model 6220/6221 Reference Manual
Return to Section 14 topics
:ARBitrary Arbitrary waveforms: 7
:DATA <NRf>
[,<NRf>, ...<NRf>]
Define arbitrary data points: -1 to +1 (100 points
maximum).
:DATA? Query the points in the arbitrary waveform.
:APPend <NRf>
[,<NRf>, ...<NRf>]
Append arbitrary data points: -1 to +1 (100
points max. per instance of command).
:POINts? Query number of points in the waveform.
:COPY <NRf> Copy arbitrary points to NVRAM: 1 to 4.
:RANGing <name> Select source ranging mode: BEST or FIXed. BEST
:RANGing? Query selected range mode.
:DURation Waveform duration:
:TIME <NRf> Set waveform time duration (seconds): 100e-9
to 999999.999 or INFinity.
INFinity
:TIME? Query waveform time duration.
:CYCLes <NRf> Set waveform duration in cycles: 1e-3 to
99999999900 or INFinity.
INFinity
:CYCLes? Query waveform duration in cycles.
:ARM Arm waveform function.
:INITiate Start waveform output.
:ABORt Abort waveform output.
:EXTRig Waveform external trigger commands: *
[:ENABle] <b> Enables/disables mode to externally trigger the
waveform generator: <b> = ON or OFF.
OFF
[:ENABle]? Query if external waveform trigger is enabled.
:ILINe <NRf> Specify trigger link input trigger line:
<NRf> = 0 (none) or 1 to 6.
0
:ILINe? Query trigger link line.
:IGNore <b> Sets whether or not to restart waveform upon
retriggering: <b> = ON or OFF.
OFF
:IGNore? Query retrigger mode.
:IVALue <NRf> Sets inactive value to output before/after
waveform: <NRf> = -1 to +1.
0.00
:IVALue? Query inactive value.
* Available with firmware revision A03 and later.
Table 14-6 (cont.)
Source command summary
Command Description Default Sec SCPI
