17-20 Calibration Model 6220/6221 Reference Manual
Return to Section 17 topics
SCPI commands — calibration
Commands for calibration are listed in Tabl e 17 - 5. Additional information for each
command is provided in added notes and several tables that follow.
1. CAL:PROT:CODE “<string>” ‘ Enter password
This command sends the calibration password/code to unlock calibration. The
code is an eight-character string that must be enclosed in single or double
quotes. The Model 6220 default code is KI006220; the default Model 6221
code is KI006221. You can change the code once calibration is unlocked by
sending a different code with this command. However, if you change the first
two characters to something other than “KI”, you will not be able to unlock cal-
ibration from the front panel.
2. CAL:PROT:LOCK ‘ Lock out calibration
This command locks out calibration. Note that the CAL:PROT:LOCK? query
will return a 1 if calibration is locked; 0 otherwise.
Table 17-5
Calibration commands
Command Description
CALibration:PROTected:CODE “<string>” Enters calibration code/password.
1
<string> = 8-character password
6220 default: KI006220
6221 default: KI006221
CALibration:PROTected:LOCK Locks out calibration.
2
CALibration:PROTected:SAVE Saves all cal data to non-volatile memory.
3
CALibration:PROTected:DATE <yyyy,mm,dd> Saves last calibration date.
4
CALibration:PROTected:NDUE <yyyy,mm,dd> Saves next calibration date.
4
CALibration:PROTected:COUNt? Queries number of times unit was calibrated.
5
CALibration:PROTected:SOURce <NRf> Calibrates active current source range.
6
CALibration:PROTected:SENSe <NRf> Calibrates compliance voltage.
7
CALibration:PROTected:GUARd:STEP1 <NRf> Voltage reading for guard calibration step 1.
8
CALibration:PROTected:GUARd:STEP1:INIT Sets up unit for step 1 of guard calibration.
8
CALibration:PROTected:GUARd:STEP2 <NRf> Voltage reading for guard calibration step 2.
8
CALibration:PROTected:GUARd:STEP2:INIT Sets up unit for step 2 of guard calibration.
8
CALibration:PROTected:WAVE:STEP1 Calibrates 6221 waveform generator.
9
