17-22 Calibration Model 6220/6221 Reference Manual
Return to Section 17 topics
Table 17-6
CAL:PROT:SOUR command parameter ranges
Source range
First parameter
(+FS)
Second parameter
(0)
Third parameter
(-FS)
2nA +1.8e-9 to +2.2e-9 -2e-11 to +2e-11 -1.8e-9 to -2.2e-9
20nA +18e-9 to +22e-9 -2e-10 to +2e-10 -18e-9 to –22e-9
200nA +180e-9 to +220e-9 -2e-9 to +2e-9 -180e-9 to –220e-9
2μA +1.8e-6 to +2.2e-6 -2e-8 to +2e-8 -1.8e-6 to –2.2e-6
20μA +18e-6 to +22e-6 -2e-7 to +2e-7 -18e-6 to –22e-6
200μA +180e-6 to +220e-6 -2e-6 to +2e-6 -180e-6 to -220e-6
2mA +1.8e-3 to +2.2e-3 -2e-5 to +2e-5 -1.8e-3 to –2.2e-3
20mA +18e-3 to +22e-3 -2e-4 to +2e-4 -18e-3 to –22e-3
100mA +90e-3 to +110e-3 -1e-3 to +1e-3 -90e-3 to –110e-3
NOTE: Parameter steps for each range may be performed in any order, but all three parameter steps for each
range must be completed.
Table 17-7
CAL:PROT:SENS command parameter ranges
Sense range
First
parameter
Second
parameter
Third
parameter
Fourth
parameter
20V +18.0 to +22.0
(full scale + curr.)
-1.05 to +1.05
(.1V at + curr.)
-18.0 to –22.0
(full scale at -curr.)
-1.05 to +1.05
(.1V at -curr.)
100V +90 to +110
(full scale + curr.)
+18.9 to +23.1
(21V at pos. curr.)
-90 to –110
(full scale at -curr.)
-18.9 to -23.1
(21V at neg. curr.)
Notes:
1. Parameter steps for each range may be performed in any order, but all four parameter steps for each range must be completed.
2. There are two internal voltage compliance ranges (20V + 100V), but externally it appears as if there is only one (100V) range.
The calibration for this range must be performed on the 2mA source range. All four 20V steps must be completed before any of
the 100V steps.
