Maintenance
7-16
be checked at the connectors at each end of the board.
Table 7-1 lists the ouptut voltages that shoud be
checked.
Symptom Repeated blowing of fuses indicates a
faulty power supply or other boards:
Disconnect the various wiring harnesses or re-
move boards and check for short circuits.
7.8.4 Micro DIN board
The micro DIN board contains several ICs and dis-
crete components for interfacing and protection.
Failures are unlikely unless caused by external
overloads. The BIT will test the micro DIN board to
some degree.
Symptom Improper communication with external
equipment via micro DIN or BNC connectors:
Check for broken or bent connector pins or exter-
nal wiring.
Check for defective BNC or micro DIN board.
7.8.5 Backplane board
The backplane board interfaces plug-in relay cards to
the digital board. If communication through the back-
plane board is faulty, check the cards and the condition
of the card edge connectors on the backplane board.
Symptom Incorrect identiÞcation of relay cards
plugged into backplane:
Move the affected relay card into the other back-
plane slot. If it is correctly identiÞed, suspect the
backplane board. If not, suspect the relay card.
Symptom Test circuit conÞgurations not functioning
properly:
Defective or improperly seated relay cards.
Defective backplane board.
7.8.6 BNC board
The BNC board contains only passive components.
Mechanical components include the power switch and
BNC connectors. The only signal cable from the BNC
board carries BNC I/O to the micro DIN board. Fail-
ures are unlikely.
Table 7-1
Power supply checks
Test
point
Output
voltage Tolerance
Rated
load Ripple/noise
J102-1 +14.6VDC ±5% 1.67A 100mV Referenced to J102-2
J102-4 +6VDC ±3% 2.5A 50mV Referenced to J102-3,
adjustable
Notes:
1. Tolerance is measured with output at 60% rated load.
2. Ripple/noise is measured by using a 12-inch twisted wire terminated with a 47µF capacitor.
