KD 702_1003_1404 Workshop Manual_cod. ED0053029340_1° ed_
3
KDW
702
KDW
1003
KDW
1404
N° 2 3 4
mm 75 75 75
mm 77.6 77.6 77.6
Cm
3
686 1028 1372
22,8:1 22,8:1 22,8:1
3600 3600 3600
N 80/1269/CEE-ISO 1585 12.5(17.0) 19.5(26.5) 26.0(35.2)
NB ISO 3046 - IFN 11.7(16) 18(24.5) 24.5(33.3)
NA ISO 3046 - ICXN 10.7(14.5) 16.5(22.4) 22.4(30.5)
Nm 40.5 67.0 84.0
RPM @ 2000 @2000 @ 2000
Nm 37@1800 37@1800 37@1800
g/KWh 320 300 325
Kg/h 0,009 0,013 0,019
Kg 66 87 98
l./1' 1240 1850 2470
m
3
/mm 43 63
88
Kg 300 300 300
a
35° 35° 35°
a
25° 25° 25°
a
**** **** ****
Technical information
TECHINICAL SPECIFICATIONS
Cylinders
Bore
Stroke
Displacements
Compression rate
Rpm
Maximum
power
Maximum torque *
Maximum Torque Available @ N° 3 PTO 3600 Rpm
Specic fuel consumption**
Oil consumption ***
Dry weight of engine
Combustion air volume at 3600 Rpm
Cooling air volume at 3600 Rpm
Axial load allowed on crankshaft (both directions)
Instant operation (up to 1 min)
Max tilt Intermittent operation (up to 30 min)
Permanent operation
* At NB power
** Referred to NB power
*** Measured at NA power
**** Depends on application
• At 3600 Rpm
•• Measured at NB power
ENGINE TYPE
KDW 702
KDW 1003 KDW 1404
