- 36 -
KD 702_1003_1404 Workshop Manual_cod. ED0053029340_1° ed_ rev. 00
5
Use protective gloves when handling the engine
Important
- Before removing the engine from the vehicle on which it is installed, disconnect the power supply, detach the fuel and
coolant supply, and all connections including the mechanical ones.
- Attach the engine to a suitable lifting device (lifting beam).
- Hook the lifting device in the engine lifting points, as shown in the gure.
- Before lifting, make sure the weight is correctly balanced by checking its barycentre.
- Close all engine openings accurately (exhaust, intake, etc.), then wash the outside and dry with a jet of compressed
air.
Important
The bracket of the lifting points have been designed to lift the engine
only. They are not intended nor approved to lift additional weights.
Do not use different methods to lift the engine than those described
herein. In case different methods are used, no warranty shall be
granted for any consequential damage.
REGULATIONS FOR LIFTING THE ENGINE
