- 39 -
KD 702_1003_1404 Workshop Manual_cod. ED0053029340_1° ed_
1
1
2
2
2
2
6
5
7
6
Air lter support
The support for air lter 1 incorporates the intake manifold and
the accelerator control box.
Remove all bolts that secure the air lter support 1 to the
cylinder head. Carefully pull the air lter support from the
cylinder head. Using suitable pliers, release the governor spring
2 from the air lter support assembly.
Replace the gasket 3.
Intake manifold – Remote air lter
Unscrew the the fastening screws 1 that x the intake duct to
the intake manifold unit.
Unscrew the two fastening screws 2 of the intake manifold from
the engine crankcase.
Lift the intake manifold and disengage the hook of the min/max
cylinder from the same manifold (g. 212).
Disassembly / Reassembly
