FUEL, COOLANT AND LUBRICANTS

198

4.4 FUEL, COOLANT AND LUBRICANTS

e Original Komatsu oil, especially developed and approved to be used in hydraulic systems.

a ASTM D975 N. 1 / EN 590 class 2

ITEM / TANK /

SYSTEM

FLUID

AMBIENT TEMPERATURE CAPACITY (l)

filling Change



Engine oil pan



OIL

API CD

3.6 3.3



Travel reduction

gears



0.3 0.3



Hydraulic system



23.8 15.2

(e)



Hydraulic system

with biodegrada-

ble oil

• See par.

“4.4.1”

23.8 15.2



Fuel



tank



DIESEL OIL 19 —

Engine



cooling



system

PERMANENT

COOLANT

4.2 —

Window washer



fluid

ethyl alcohol

based deter-

gent

1—

Greasing GREASE

Lithium EP+MoS2 (NLGI 2)

-30 -20 -10 0 10 20 30 40 50°C

-22 -4 14 32 50 68 86 104 122°F

ASTM D975 N. 2

SAE 30

SAE 10W-30

SAE 10W

SAE 30

SAE 10W

SAE 10W-30

SAE 15W-40

HO46-HM

WEAM012405
