PREPARATION FOR EQUIPMENT INSTALLATION (only for machines with proportional controls)
271
6.5.5 USING THE EQUIPMENT
q
In case you are not working with the breaker or two-way flow equipment, fit this switch on the normal
mode. If an operation mode is selected, the involuntary activation of the proportional equipment switch
or the breaker switch can cause serious incidents.
The equipment works as described below.
6.5.5.1 WHEN USING HAMMER
1st attachment line
Precautions for use
Make sure that the selection valve (1) is in position 1 way (for
breaker use) (b).
Pressing the switch, the oil flows continuously towards the piping
on the left side of the boom (operator seat side) and the breaker is
activated. Press the switch again to stop the breaker.
To Next Page
