SPECIFICA
TIONS
254
6.2
SPECIFICA
TIONS
Hydraul
ic specif
icati
ons
q
Max. Servic
e valve flo
w (1st attachmen
t) 35 litre
s/min
q
S
tandard Servic
e valve wo
rking pressure (1s
t attachment) 20
.6 M
Pa
(206
bar)
q
Optional
Safety s
ervic
e valve
working
press
ure (1st at
tachment)
— MPa (
—
bar)
q
S
tandard
Servic
e valv
e safet
y press
ure (1
st attachm
ent) —
MPa (
— b
ar)
6.2.1
ARM-PIN INFORMA
TION
1
3
A - A
B - B
RKA28270
4
AA
B
B
2
1
1
18 mm
0
- 0.5
3
1
18 mm
0
- 0.5
2
30
mm
- 0.090
- 0.130
4
30 mm
- 0.090
- 0.130
WEAM012405
255
257
