TECHNICAL SPECIFICA
TIONS
244
5.1
T
ECHNICAL SPECIFICA
TION
S
Unit of
measurement
PC16R-3 (
PC16R-3
HS)
Operating mass
(kg)
1620
(1770
)
Bucket capacity
(m3)
0.044
Engine
-
Komat
su
3D67E-2A
diesel
engine
Engine power (
ISO 14396: 2002)
KW (HP)/rpm
1
1.8(1
6.0)/2
600
A
T
otal
length
mm
3500
B
T
otal
height
mm
2320
C
T
otal
width
mm
1000
D
T
rack wid
th
mm
230
E
Swing radi
us
mm
825
F
T
otal
length of
the
tracks
mm
1370
G
T
umbler
distance
mm
1015
Min. gro
und clear
ance
mm
205
T
rav
el speed
(low/
high)
km/h (MPH)
2.2/4.2
(1.4/2.6)
Swing speed
rpm
8.9
WEAM012405
245
247
