Repair manual KTM LC4 Art.-Nr. 3.206.014 -E
11-45E
625 SC 625 SC SUPERMOTO
Frame Central chrome-moly-steel frame
Fork White Power 4357 MXMA
Wheel travel front/rear 295 / 320 mm (11,8 / 12,8 in) 270 / 320 (10,8 / 12.8 in)
Rear suspension Central shock absorber (WP BAVP3612) with PRO-LEVER linkage to rear- swing-arm with needle bearing
Front brake Disc brake with carbon-steel brake disc, brake caliper floated
Front brake disc Ø 260 mm (10,4 in) Ø 320 mm (12.8 in)
Rear brake Disc brake with carbon-steel brake disc 220 mm (8.8 in), brake caliper floated
Tyres front 90/90-21 120/70-17
Air press. offroad 1,0 bar (14 psi) -
Air press. road 1,8 bar (26 psi) 2,0 bar (29 psi)
Tyres rear 140/80-18 160/60-17
Air press offroad
1,2 bar (17 psi) -
Air press. road 2,0 bar (29 psi) 2,2 bar (32 psi)
Fuel tank capacity 9 liter (2,3 US gallons), 1.5 liter (0,4 US gallons) reserve
Final drive ratio 16:40 (15:50) t 17:38t
Chain X – Ring 5/8 x 1/4"
Bulps headlight . . . . . . . . . . . . . H4 12V 60/55W (socket P43t)
parking light . . . . . . . . . . . 12V 5W (socket W2,1x9,5d)
indicator lamps . . . . . . . . . 12V 1,2W (socket W2x4,6d)
brake – rear light . . . . . . . 12V 21/5 W (socket BaY15d)
flasher light . . . . . . . . . . . 12V 10W (socket Ba15s)
license plate illmination . . . 12V 5W (socket W2,1x9,5 d)
Steering angle 62,5 ° 63°
Wheel base 1510 ± 10 mm (59.4 ± 0.4 in)
Seat high 950 mm (38 in) 920 mm (36.8 in)
Ground clearance 340 mm (13,6 in) 300 mm (12 in)
Dead weight without fuel 122 kg (269 lbs) 123 kg (271 Ibs)
TECHNICAL SPECIFICATIONS - CHASSIS 625 SC, 625 SC SUPERMOTO 2002
625 SC
625 SC SUPERMOTO
WP 0518W712 WP 0518W722
Compression adjuster
20 14
Rebound adjuster
12 14
Spring
4,2 N/mm 5,0 N/mm
Spring preload
5 mm 9 mm
Air chamber length
140 mm 130 mm
Fork oil
SAE 5 SAE 5
STANDARD ADJUSTMENT - FORK
625 SC
625 SC SUPERMOTO
WP 0118W714 WP 0118W721
Compression adjuster
35
Rebound adjuster
57
Spring
63 / 260 75 / 260
Spring preload
23 mm 15 mm
STANDARD-ADJUSTMENT - SHOCK ABSORBER
