TECHNICAL SPECIFICATIONS – CHASSIS 640 LC4 2005
640 LC4 ENDURO 640 LC4 SUPERMOTO
Frame Central chrome-moly-steel frame
Fork White Power – Up Side Down 4357 MXMA White Power - Up Side Down 4860 MXMA
Wheel travel front/rear 275 / 275 mm 275 / 260 mm
Rear suspension Central shock absorber (WP BAVP) with PRO-LEVER linkage to rear- swing-arm with needle bearing
Front brake
Disc brake with carbon-steel brake disc,
2-piston brake caliper floated
Disc brake with carbon-steel brake disc,
4-piston brake caliper
Front brake disc Ø 300 mm Ø 320 mm
Rear brake Disc brake with carbon-steel brake disc B 220 mm (8.8 in), brake caliper floated
Tyres front
Air press. road, driver only
Air press. road with passenger
90/90-21
1,8 bar
2,0 bar
120/70-17
2,0 bar
2,2 bar
Tyres rear
Air press. road, driver only
Air press. road with passenger
130/80-18
2,0 bar
2,2 bar
160/60-17
2,2 bar
2,4 bar
Fuel tank capacity 11,2 liter, 2.5 liter reserve
Final drive ratio 16:42t 17:42t
Chain 5/8 x 1/4" X-Ring
Headlight
Parking light
Instrument lights
Indicator lamps
Brake light
Rear light
Flasher light
License plate illmination
H4 12V 60/55 W (Sockel P43t)
12V 5W (Sockel W2,1x9,5d)
LED
LED
12V 21/5W (Sockel BaY15d)
12V 21/5W (Sockel BaY15d)
12V 10W (Sockel Ba15s)
12V 5W (Sockel W2,1x9,5d)
H4 12V 60/55 W (Sockel P43t)
12V 5W (Sockel W2,1x9,5d)
LED
LED
12V 10W (Sockel Ba15s)
12V 5W (Sockel W2,1x9,5d)
12V 10W (Sockel Ba15s)
12V 5W (Sockel W2,1x9,5d)
Battery maintenance-free battery 12V 8,6 Ah
Steering angle 62° 63°
Wheel base 1510 ± 10 mm (59.4 ± 0.4 in)
Seat high 910 mm 910 mm
Ground clearance 300 mm 280 mm
Dead weight without fuel 144 kg 145 kg
Max. permissible front axle load 150 kg
Max. permissible rear axle load 200 kg
Max. permissible laden weight 350 kg
STANDARD ADJUSTMENT - FORK
640 LC4
Enduro
640 LC4
Supermoto
WP 05187A02 WP 14187A07
Compression adjuster 20 15
Rebound adjuster 12 15
Spring 4,2 N/mm 4,4 N/mm
Spring preload 5 mm 18 mm
Air chamber length 150 mm 120 mm
Fork oil SAE 5 SAE 5
STANDARD-ADJUSTMENT - SHOCK ABSORBER
640 LC4
Enduro
640 LC4
Supermoto
WP 01187A03 WP 01187A02
Compression adjuster 3 4
Rebound adjuster 7 8
Spring 66 / 260 70 / 260
Spring preload 23,5 mm 20 mm
