4-3E
Removing the clutch release lever and the oil hoses
– Undo bolt 1 and remove the clutch release lever.
– Remove the two banjo bolts
2 together with the seal rings and
remove both oil hoses.
Removing the oil filter
– Remove all three bolts 3 and take off the oil filter cover together
with the O-ring or gasket.
–Take the oil filter out of the engine housing.
Removing the EPC wiring harness
– Undo the 3 bolts 4 and remove the EPC wiring harness.
Removing the ignition (Kokusan 4K-2)
– Undo 4 bolts and remove the ignition cover with the stator incl.
gasket.
1
2
2
3
4
4
