KTM 400-660 LC4 1998-2005 User Manual

Repair manual KTM LC4 Art.-Nr. 3.206.014 -E
11-51E
625 SXC
Frame Central chrome-moly-steel frame
Fork White Power 4357 MXMA
Wheel travel front/rear 295 / 320 mm (11,8 / 12,8 in)
Rear suspension Central shock absorber (WP BAVP4681) with PRO-LEVER linkage to rear- swing-arm with needle bearing
Front brake Disc brake with carbon-steel brake disc, brake caliper floated
Front brake disc Ø 260 mm (10,4 in)
Rear brake Disc brake with carbon-steel brake disc  220 mm (8.8 in), brake caliper floated
Tyres front 90/90-21
Air press. offroad 1,0 bar (14 psi)
Air press. road 1,8 bar (26 psi)
Tyres rear 140/80-18
Air press offroad 1,2 bar (17 psi)
Air press. road 2,0 bar (29 psi)
Fuel tank capacity 9 liter (2,3 US gallons), 2.5 liter (0,6 US gallons) reserve
Final drive ratio 16:40 ( USA 15:50) t
Chain X – Ring 5/8 x 1/4"
Bulps headlight . . . . . . . . . . . . . HS1 12V 35/35W (socket PX43t)
parking light . . . . . . . . . . . 12V 5W (socket W2,1x9,5d)
indicator lamps . . . . . . . . . 12V 1,2W (socket W2x4,6d)
brake – rear light . . . . . . . 12V 21/5 W (socket BaY15d)
flasher light . . . . . . . . . . . 12V 10W (socket Ba15s)
license plate illmination . . . 12V 5W (socket W2,1x9,5 d)
Battery maintenance-free battery 12V 8,6 Ah
Steering angle 62,5 °
Wheel base 1510 ± 10 mm (59.4 ± 0.4 in)
Seat high 980 mm (39,2 in)
Ground clearance 360 mm (14,4 in)
Dead weight without fuel 132 kg (291 lbs)
TECHNICAL SPECIFICATIONS - CHASSIS 625 SXC 2003
625 SXC
WP 0518X729
Compression adjuster
20
Rebound adjuster
12
Spring
4,2 N/mm
Spring preload
5 mm
Air chamber length
140 mm
Fork oil
SAE 5
STANDARD ADJUSTMENT - FORK
625 SXC
WP 0118X725
Compression adjuster
3
Rebound adjuster
5
Spring
63 / 260
Spring preload
23 mm
STANDARD-ADJUSTMENT-SHOCK ABSORBER
