Repair manual KTM LC4 Art.-Nr. 3.206.024 -E

11-75F

Hexagon nut at primary gear M20x1,5 Loctite 243 + 170 Nm

Collar nut flywheel (LC4, ADVENTURE, DUKE) M16x1,25 links 150 Nm

Collar nut flywheel (SC, SXC) M12x1 left 60 Nm

Hexagon nut for inner clutch hub M18x1,5 Loctite 243 + 90 Nm

Collar bolt clutch springs M6 10 Nm

Kickstarter stop bolt M12x1,5 50 Nm

Allen head bolt freewheel hub (E-STARTER) M6x12 12.9 Loctite 2701 + 16 Nm

Allen head bolt freewheel hub (E-STARTER) M6x12.5 8.8 Loctite 2701 + 12 Nm

Allen head bolts oil pumps M6 Loctite 243 + 8 Nm

Collar bolts oil pumps (from modell 2003 on) M6 Loctite 243 + 10 Nm

Hexagon bolt camshaft gear M10 Loctite 243 + 35 Nm

Allen head bolts cylinder head top section M6x25/M6x35/M6x65/M6x70 (8.8) 8 Nm

Allen head bolts cylinder head top section M6x50/M6x55 (12.9) 15 Nm

Bolts cylinder head top section (from model 2003 on) M6 (8.8) 10 Nm

Bolts cylinder head top section (from model 2003 on) M7 (12.9) 15 Nm

Cylinder head to cylinder M8 25 Nm

Cylinder head to cylinder M6 8 Nm

Cylinder head to cylinder (from model 2003 on) M6 10 Nm

Cylinder head bolts M10 50 Nm

Cylinder head bolts (from the 2004 model) M10 10/53 Nm

Collar nuts at cylinder base M10 50 Nm

Plug at cylinder head (SC) M10 20 Nm

Hexagon bolt chain sprocket 8.8 M10 Loctite 243 + 40 Nm

Hexagon bolt chain sprocket 12.9 M10 Loctite 243 + 60 Nm

Nut chain sprocket M20x1,5 Loctite 243 + 60 Nm

Oil drain plug M22x1,5 30 Nm

Magnetic plug M12x1,5 20 Nm

Plug Bypass valve M12x1,5 20 Nm

Banjo bolts oil lines M8x1 10 Nm

Banjo bolts oil lines M10x1 15 Nm

Jet screw clutch cover M8 10 Nm

Plug timing-chain tensioner M12x1,5 20 Nm

Timing-chain tensioner to cylinder M6 Loctite 243 + 8 Nm

Timing-chain tensioner to cylinder (from model 2003 on) M6 10 Nm

Timing-chain guide to cylinder M12x1,25 Loctite 243 + 8 Nm

Hexagon bolt timing-chain guide M6 Loctite 243 + 10 Nm

Tension guide M8 Loctite 243 + 15 Nm

Timing-chain securing guide M6 8 Nm

Allen head bolt timing-chain securing guide (from model 2003 on) M6 Loctite 243 + 10 Nm

Counternuts valve adjusting screws M7x0,75 16 Nm

Crankshaft locking bolt M8 20 Nm

Spark plug M12x1,25 20 Nm

Engine mounting bolt M8 40 Nm

Engine mounting bolt M10 70 Nm

Retaining plate for main shaft bearing M6 Loctite 648 + 8 Nm

Retaining plate for main shaft bearing (from model 2003 on) M6 Loctite 648 + 10 Nm

Shift mechanism support, securing device for bearing M5 Loctite 243 + 6 Nm

Shift mechanism support M6 Loctite 243 + 8 Nm

Shift mechanism support (from model 2003 on) M6 Loctite 243 + 10 Nm

Shift drum locating M6 Loctite 243 + 8 Nm

Engine housing, clutch cover, ignition cover M6 10 Nm

Water pump cover M6 10 Nm

Bolts for pulse generator M5 Loctite 243 + 6 Nm

Stator (SC) M6 Loctite 243 + 8 Nm

Stator (E-Start) M5 Loctite 243 + 6 Nm

Kick starter M8 25 Nm

Shifting lever M6 Loctite 222 + 10 Nm

Oil filter cover M6 10 Nm

Microfilter cover (SC) M5 6 Nm

Starter flange, starter cover M6 10 Nm

AH bolt for slave cylinder M6 Loctite 243 + 10 Nm

Starter M6 10 Nm

Valve cover M6 10 Nm

Exhaust flange M6 10 Nm

AH screw for decompression shaft lever M6 Loctite 243 + 10 Nm

Retaining shim for ignition (SC) M5 Loctite 243 + 6 Nm

Contact screws M10 15 Nm

Oil jet M6x0,75 Loctite 648 + 10 Nm

Plug for gear detection sensor M10 25 Nm

Water pump wheel M5 Loctite 243 + 6 Nm

Thermostat case M6 6 Nm

Closing panel for ignition (SC) M5 Loctite 243 + 6 Nm

Pulse generator M5 Loctite 243 + 6 Nm

Other bolts, engine M5 6 Nm

M6 10 Nm

TIGHTENING TORQUE - ENGINE
