TECHNICAL SPECIFICATIONS – CHASSIS 640 DUKE 2005
CHASSIS 640 DUKE II
Frame Central chrome-moly-steel frame
Fork type . . . . . . . . . . . . . . . . . . . . . . . . . . .WP 4357 MXMA 05187A03
wheel travel . . . . . . . . . . . . . . . . . . . . .140 mm (5.5 in)
standard adjustment compression . . . . . .driver only = 14, with passenger = 14
standard adjustment rebound . . . . . . . . .driver only = 16, with passenger = 16
fork leg projection upper fork bridge . . . .3 mm (0.12 in)
oil capacity per fork leg . . . . . . . . . . . . .appr. 400 ccm (24 cubic in) / SAE 5
air chamber lenght . . . . . . . . . . . . . . . .100 mm (4 in)
Rear suspension WP central shock absorber with PRO-LEVER linkage to rear- swing-arm with needle bearing
Shock absorber type . . . . . . . . . . . . . . . . . . . . . . . . . . .WP central shock absorber BAVP 4681 01187A05
rear wheel travel . . . . . . . . . . . . . . . . . .170 mm (6.7 in)
standard adjustment compression . . . . . .driver only = 3, with passenger = 5
standard adjustment rebound . . . . . . . . .driver only = 5, with passenger = 6
spring preload . . . . . . . . . . . . . . . . . . . . driver only = 18 mm (0.7 in), with passenger = 23 mm (0.9 in)
spring type . . . . . . . . . . . . . . . . . . . . . .80 - 260
Front brake Disc brake with carbon-steel floated brake disc Ø 320 mm (12.6 in) and 4-piston brake caliper
Rear brake Disc brake with carbon-steel brake disc Ø 220 mm (8.7 in) and single-piston brake caliper floated
Tyres front: 120/70 R 17 58H - MTR 01 rear: 160/60 R 17 69H - MTR 02
Air pressure rider only 2.0 bar (29 psi) 2.2 bar (32 psi)
Air pressure with passenger 2.2 bar (32 psi) 2.4 bar (35 psi)
Fuel tank capacity 11.2 liters (2.96 US gallons), out of this 2.5 liters (0.62 US gallons) reserve
Final drive ratio 17 : 42
Chain X-ring 5/8 x 1/4"
Lamps low beam . . . . . . . . . . . . . . . . . . . . . . .HB3 12V 60W (socket P20d)
high beam . . . . . . . . . . . . . . . . . . . . . .HB3 12V 60W (socket P20d)
parking light . . . . . . . . . . . . . . . . . . . . .12V 5W (socket W2,1x9,5d)
speedometer, tachometer light . . . . . . . .12V 1,7W (socket W2x4,6d)
indicator lamp . . . . . . . . . . . . . . . . . . . .12V 1,2W (socket W2x4,6d)
stop and taillight . . . . . . . . . . . . . . . . . .12V 21/5W (socket BaY15d)
flasher . . . . . . . . . . . . . . . . . . . . . . . . .12V 10W (socket Ba15s)
Battery maintenance-free battery 12V 8Ah
Steering angle 63.5°
Wheel base 1460 ± 15 mm (57.5 ± 0.6 in)
Seat high 900 mm (35.5 in)
Ground clearance 280 mm (11 in)
Dead weight without fuel 148 kg (327 lbs)
Max. permissible front axle load 150 kg (331 lbs)
Max. permissible rear axle load 200 kg (441 lbs)
Max. permissible laden weight 350 kg (773 lbs)
