Repair manual KTM LC4 Art.-Nr. 3.206.014 -E
11-63E
TECHNICAL SPECIFICATIONS - CHASSIS 640 LC4 ADVENTURE 2004
640 LC4 Adventure
Frame Central chrome-moly-steel frame
Fork WP USD MXMA 4860
Wheel travel front/rear 275/300 mm (10,5/12 in)
Rear suspension
Central shock absorber (WP BAVP4681) with PRO-LEVER linkage to rear-swingarm with needle bearing
Front brake Disc brake, 2 perforated brake discs Ø 300 mm (11,8 in), brake caliper floated
Rear brake Disc brake, perforated brake disc Ø 220 mm (8,7 in), brake caliper floated
Tyresfront 90/90-21 Enduro3
Air pressure offroad 1,8 bar (21 psi)
Air press. road, driver only
2,0 bar (29 psi)
Tyres rear 140/80-18 Enduro3
Air press. road, driver only
2,0 bar (29 psi)
Air press. road, with passenger
2,2 bar (32 psi)
Fuel tank capacity 25,5 liter (6,7 US gallons) of that 3,5 liter (0,9 US gallons) reserve
Final drive ratio 16 : 42
Chain 5/8 x 1/4 "X-Ring
Lampenbestückung head light . . . . . . . . . . . . . . . . . . . . . .H1 12V 55W (Sockel P14,5S)
parking light . . . . . . . . . . . . . . . . . . . .12V 2W (Sockel Ba9s)
brake- rear light . . . . . . . . . . . . . . . . .12V 21/5W (Sockel BaY15d)
flasher light . . . . . . . . . . . . . . . . . . . . .12V 10W (Sockel Ba15s)
license plate illintion . . . . . . . . . . . . . .12V 5W (Sockel W2,1x9,5d)
Battery maintenance-free battery 12V 8Ah
Steering angle 62,5°
Wheel base 1510 ± 10 mm (59,4 ± 0,4 in)
Seat high 945 mm (37,2 in)
Ground clearance 315 mm (12,4 in)
Dead weight without fuel
158 kg (340 lbs)
Max. permissible front axle load
150 kg (331 lbs)
Max. permissible rear axle load
230 kg (507 lbs)
Max. permissible laden weight
380 kg (839 lbs)
WP BAVP3612
0118Y735
Compression adjuster 6
Rebound adjuster 7
Spring 70/260
Spring preload 27 mm (0,9 in)
STANDARD-ADJUSTMENT - SHOCK ABSORBER
WP 4860 MXMA
1418Y753
Compression adjuster 14
Rebound adjuster 14
Spring 4,4 N/mm
Spring preload 4 mm
Air chamber length 120 mm
Capacity per fork leg ca 420 ccm
Fork oil SAE 5
STANDARD ADJUSTMENT - FORK
