KTM 400-660 LC4 1998-2005 User Manual

11-68F
625 SXC 625 SMC
Frame Central chrome-moly-steel frame
Fork White Power 4357 MXMA White Power 4860 MXMA
Wheel travel front/rear 295 / 320 mm (11,8 / 12,8 in) 265 / 300 mm
Rear suspension Central shock absorber (WP BAVP4681) with PRO-LEVER linkage to rear- swing-arm with needle bearing
Front brake Brake caliper floated 4 piston brake caliper
Front brake disc Disc brake with carbon-steel brake disc Ø 260 mm Disc brake with carbon-steel brake disc Ø 320 mm
Rear brake Disc brake with carbon-steel brake disc B 220 mm (8.8 in), brake caliper floated
Tyres front 90/90-21 120/70-17
Air press. offroad / SM 1,0 - 1,5 bar 1,0 - 1,5 bar
Air press. road 1,8 bar 2,0 bar
Tyres rear 140/80-18 160/60-17
Air press offroad / SM 1,0 - 1,5 bar 1,6 bar
Air press. road 2,0 - 2,2 bar 2,2 - 2,4 bar
Fuel tank capacity 9 liter (2,3 US gallons), 2,5 liter (0,6 US gallons) reserve 9,2 Liter, 2,5 Liter Reserve
Final drive ratio 16:40 16:38
Chain 5/8 x 1/4" X-Ring
Headlight
Parking light
Indicator lamps
Brake light
Rear light
Flasher light
License plate illmination
12V 35/35 W (Sockel P43t)
12V 5W (Sockel W2,1x9,5d)
12V 1,2W (Sockel W2x4,6d)
12V 21/5W (Sockel BaY15d)
12V 21/5W (Sockel BaY15d)
12V 10W (Sockel Ba15s)
12V 5W (Sockel W2,1x9,5d)
12V 35/35 W (Sockel P43t)
12V 5W (Sockel W2,1x9,5d)
12V 1,2W (Sockel W2x4,6d)
12V 21W (Sockel Ba15s)
12V 5W (Sockel W2,1x9,5d)
12V 10W (Sockel Ba15s)
12V 5W (Sockel W2,1x9,5d)
Battery maintenance-free battery 12V 8,6 Ah
Steering angle 62,5° 63°
Wheel base 1510 ± 10 mm (59.4 ± 0.4 in) 1510 ± 10 mm
Seat high 980 mm (39,2 in) 910 mm
Ground clearance 360 mm (14,4 in) 290 mm
Dead weight without fuel 132 kg (291 lbs)
STANDARD ADJUSTMENT - FORK
625 SXC
05187A01
625 SMC
14187A07
Compression adjuster 20 23
Rebound adjuster 12 19
Spring 4,2 N/mm 4,4 N/mm
Spring preload 5 mm 28 mm
Air chamber length 140 mm 110 mm
Fork oil SAE 5 SAE 5
STANDARD-ADJUSTMENT-SHOCK ABSORBER
625 SXC
01187A01
625 SMC
01187A02
Compression adjuster 3 3
Rebound adjuster 5 5
Spring 63 / 260 70 / 260
Spring preload 23 mm 20 mm
TECHNICAL SPECIFICATIONS – CHASSIS 625 SXC / SMC 2005
