BRAKES 120
11.15Removing rear brake linings x
Warning
Danger of accident Brake system failure.
– Maintenance work and repairs must be carried out professionally. (Your authorized KTM workshop will be glad to help.)
301830-10
– Press the brake caliper onto the brake disc by hand in order to push back the brake pis-
ton.
100064-10
– Loosen the screw 1 while holding the hexagonal head 2 of the bearing bolt. Unscrew
the screw by approx. 10 turns and use the screw to press the bearing bolt out of the
brake caliper. Remove screw.
