CONTROLS 25
5.9Choke
301780-10
The choke 1 is fitted on the left side of the carburetor.
Activating the choke function frees an opening through which the engine can draw extra
fuel. This gives a richer fuel-air mixture, which is needed for a cold start.
Info
If the engine is warm, the choke function must be deactivated.
Possible states
• Choke function activated – The choke lever is pulled out to the stop.
• Choke function deactivated – The choke lever is pushed in to the stop.
5.10Shift lever
301783-10
The shift lever 1 is mounted on the left side of the engine.
