MAINTENANCE WORK ON THE CHASSIS 77
10.12Installing the front trim
301820-11
– Connect the plug-in connector of the emergency OFF switch with the rip cord and posi-
tion the front trim.
– Mount all screws.
– Fully tighten screws 1.
Guideline
Screw on fuel tank M6 6 Nm (4.4 lbf ft)
– Fully tighten screws 2.
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
– Install the front cover. ( p. 72)
