TECHNICAL DATA - FRONT SHOCK ABSORBER 176
Shock absorber part number 03.18.7J.16
Shock absorber WP Suspension 3612 BAVP DCC
Compression damping, high-speed
Comfort 1.5 turns
Standard 1 turn
Sport 1 turn
Compression damping, low-speed
Comfort 20 clicks
Standard 15 clicks
Sport 12 clicks
Rebound damping
Comfort 20 clicks
Standard 15 clicks
Sport 12 clicks
Cross over 19±1.5 mm (0.75±0.059 in)
Spring preload
Comfort 3 mm (0.12 in)
Standard 5 mm (0.2 in)
Sport 8 mm (0.31 in)
Spring rate, main spring
Weight of rider: 64… 75 kg (141… 165 lb.) 21… 26 N/mm (120… 148 lb/in)
Weight of rider: 75… 85 kg (165… 187 lb.) 24… 29 N/mm (137… 166 lb/in)
Weight of rider: 85… 95 kg (187… 209 lb.) 27… 32 N/mm (154… 183 lb/in)
Spring rate, auxiliary spring 40 N/mm (228 lb/in)
Spring length, main spring 275 mm (10.83 in)
