KTM 505 SX User Manual

TECHNICAL DATA - ENGINE TIGHTENING TORQUES 169
Jet, engine case breather M4 On block
Loctite
®
243™
Oil jet, cam lever lubrication M4 6 Nm (4.4 lbf ft)
Loctite
®
243™
Oil jet, piston cooling M4 4 Nm (3 lbf ft)
Loctite
®
243™
Locking screw for bearing M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Oil jet, clutch oil supply M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, bearing bolt of oil pump idler
shaft
M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, camshaft bearing retaining
bracket
M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, ignition pulse generator M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, ignition pulse generator adapter M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, locking lever M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, oil filter cover M5 6 Nm (4.4 lbf ft) –
Screw, oil pump cover M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, stator bracket M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, stator cable holder M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, timing train axle retaining
bracket
M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Nut, cylinder head M6 10 Nm (7.4 lbf ft) Lubricated with engine oil
Nut, water-pump wheel M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Oil jet, timing chain tensioner M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, alternator cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch slave cylinder M6 10 Nm (7.4 lbf ft) –
