CONTROLS 21
5.4Kill switch/emergency OFF switch with rip cord
301777-10
The kill switch/emergency OFF switch 1 is mounted on the left in front of the fuel tank.
Kill switch 4 is used to switch off the engine under normal circumstances.
The emergency OFF switch shuts the engine off if the rider falls off the vehicle.
A rip cord is attached to clip 2. It can be attached to the clothing of the rider by means of
carabiner 3.
Possible states
• Clip is pulled off – The ignition circuit is interrupted, a running engine stops and a
non-running engine will not start.
• Clip is mounted – The ignition circuit is closed and the engine can be started.
• Clip mounted and kill switch pressed – The ignition circuit is interrupted, a running
engine stops and a non-running engine will not start.
5.5Electric starter button
301793-10
Electric starter button 1 is fitted on the left side of the handlebar.
Possible states
• Electric starter button in basic position
• Electric starter button is pressed – In this position, the electric starter is actuated.
