ELECTRICAL SYSTEM 133
301833-10
– The main fuse 1 is located in the starter relay 2 in front of the battery.
– Remove protection covers 3.
– Remove the faulty main fuse.
Info
You can recognize a blown fuse by its broken filament A.
Warning
Fire hazard The electrical system can be overloaded if the wrong fuses are
used.
– Use only fuses with the prescribed amperage. Never by-pass or repair fuses.
– Insert the new fuse.
Fuse (58011109120)
Tip
Replacement fuse 4 should always be present in the starter relay to make sure
it is available when needed.
– Replace the protection covers.
13.5Changing the fuses of individual power consumers
– Remove the front cover. ( p. 72)
– Switch off all power consumers and switch off the engine.
