MAINTENANCE WORK ON THE ENGINE 154
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations.
– Place a suitable container under the engine.
301842-10
– Loosen screw plug 1 by striking it lightly with a hammer a few times.
– Remove plug 1 with oil screen 2 and the O-rings.
– Drain the remaining engine oil.
– Thoroughly clean the parts and sealing area.
– Mount and tighten screw plug 1 with oil screen 2 and the O-rings.
Guideline
Plug, oil screen M32x1.5 30 Nm
(22.1 lbf ft)
Lubricated with
engine oil
16.6Installing the oil filter x
301844-10
– Fill oil filter 1 with engine oil and place it in the oil filter container.
