TECHNICAL DATA - REAR SHOCK ABSORBER 178
Shock absorber part number 15.18.7J.16
Shock absorber WP Suspension PDS 4618 BAVP DCC
Compression damping, high-speed
Comfort 1.5 turns
Standard 1 turn
Sport 1 turn
Compression damping, low-speed
Comfort 20 clicks
Standard 15 clicks
Sport 15 clicks
Rebound damping
Comfort 20 clicks
Standard 15 clicks
Sport 15 clicks
Cross over 19±1.5 mm (0.75±0.059 in)
Spring preload
Comfort 3 mm (0.12 in)
Standard 5 mm (0.2 in)
Sport 3 mm (0.12 in)
Spring rate, main spring
Rider weight: 65… 75 kg (143… 165 lb.) 70 N/mm (400 lb/in)
Rider weight: 75… 85 kg (165… 187 lb.) 74 N/mm (423 lb/in)
Rider weight: 85… 95 kg (187… 209 lb.) 78 N/mm (445 lb/in)
Spring rate, auxiliary spring 100 N/mm (571 lb/in)
Spring length, main spring 200 mm (7.87 in)
