KTM 505 SX User Manual

MAINTENANCE WORK ON THE CHASSIS 89
10.22Adjusting the fork offset x
Info
The left and right fork offset should have the same settings.
The operations are the same on the left and right.
– Raise the vehicle with the lifting gear. ( p. 67)
300274-11
– Remove screws 1 with bushings 2.
– Place the A-arm with bushings 2 in the desired position. Mount and tighten screws 1.
Guideline
Screw, A-arm top M10x52 45 Nm
(33.2 lbf ft)
– Remove the vehicle from the lifting gear. ( p. 67)
10.23Toe width of rear axle
301794-10
The toe width A can be adjusted by installing the spacer in various ways.
Difference between
narrow/wide toe
76 mm (2.99 in)
