20 GV 640 Service Manual
For internal use only
5.1.2 Removing
1. Remove the 2 screws on the front of the side
panel.
2. Fold the top of the side panel outwards.
3. Push the side panels downwards and
remove them from the retaining clips of the
base pan.
5.2 Outer door
5.2.1 Installation
Position the insulation mats and the force trans-
ducer.
Close the inner door but do not engage it.
1. Push the outer door under the control panel
with the top at an angle
2. Press the outer door onto the inner door.
Screw from the inside with the door slightly
open.
Please note!
Use 4x11mm screws.
