68 GV 640 Service Manual
For internal use only
7.4.3 Replacing the dispenser
This is only possible if the outer door or the fascia have been removed.
Removing
1. Take the cable channel out of the catches.
2. Disconnect the plug connection.
Cuts on sharp edges:
Use protective gloves.
Removal 2
1. Carefully bend the metal clamps away from
the dispenser.
2. Press the dispenser carefully to the inside,
making sure that it does not fall into the
dishwasher.
Installation
1. Before installing the dispenser bend the
metal clamps back to their original position.
2. Engage the dispenser evenly into the door,
making sure that all 8 catches have
engaged.
3. Mount the cable guide.
4. Restore the plug connection.
7.4.4 Mounting the detergent cover
1. Suspend a spring by the long end into the
dispenser.
2. Suspend the short end of the spring in the
dispenser cover.
3. Press the cover into the dispenser.
