GV 640 Service Manual 21
For internal use only
5.2.2 Removing
1. Remove the outer door from each side of the
inner door by removing the 3 screws.
2. Hold the outer door on the sides to prevent it
from falling down.
5.3 Base panel
5.3.1 Removing
1. Remove the base panel by removing the Torx
screws.
2. Lift the panel upwards out of the catches and
remove it.
5.3.2 Installation
1. Position the base panel in the catches.
2. Press it upwards and screw it tight.
Please note!
The six panel screws at the top do
not need to be removed when the
outer door is taken off.
