Commissioning
Controller inhibit
6
6.4
6.4-1
EDSVF9333V EN 3.0-06/2005
6.4 Controller i nhibit
If the controller inhibit is active, the power outputs are inhibited.
ƒ The drive idles to standstill.
ƒ Status display of keypad: Pulse inhibit
ƒ Status display at the controller: The green LED is blinking.
Danger!
Do not use the function ”Controller inhibit” (DCTRL1-CINH) as
emergency-off. The controller inhibit only inhibits the power
outputs and does not separate the controller from the mains!
The drive could start any time again.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0040 Ctrl enable 0
Controller enable
z Controller can only be enabled
if X5/28 = HIGH
6.4-1
0 Ctrl inhibit Controller inhibited
1 Ctrl enable Controller enabled
Via terminal X5/28:
ƒ LOW level at the terminal activates the controller inhibit (not
invertible)
ƒ HIGH l evel enables the controller again
Via the keyboard of the keypad (condition: C0469 = 1):
ƒ activates the controller inhibit
ƒ enables the controller again
Via code C0040:
ƒC0040=0activatesthecontrollerinhibit
ƒC0040=1enablesthecontrolleragain
Note!
ƒ The sources for controller inhibit are AND’ed, i.e. the drive only
starts again if the controller inhibit is deactivated for all signal
sources.
ƒ The restart begins with zero speed, i.e. with the centrifugal
masses still rotating an overcurrent may occur if the flying
restart circuit is not active.
Description
Activation
