Configuration
Function blocks
Master frequency output (DFOUT)
8
8.2
8.2.3
8.2-9
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0540
Function 0
Function selection, function block
DFOUT
z Output signal at X10
8.2-8
0 Analog input Analog input Signal at DFOUT-AN-IN is output.
Zero track can be input externally.
1 PH diff input Phase difference
input
Signal at DFOUT-DF-IN is output.
Zero track can be input externally.
2 Not assigned
3 Not assigned
4 X10=X9 X9 is output on
X10
The input signals are buffered
C0030 is without function
5 X10=X8 X8 is output on
X10
C0541
CFG: an-in 5001 MCTRL-NACT Selection list 1 Configuration of analog input
signal, function block DFOUT
z Signal in [%] of C0011
C0542
CFG: DF-IN 1000 FIXEDPHI-0 Selection list 4 Configuration of input signal,
function block DFOUT
z Speed signal
C0544
CFG: SYN-RDY 1000 FIXED0 Selection list 2 Configuration of digital input
signal, function block DFOUT
z DFOUT-SYN-RDY = HIGH:
Generating a zero pulse
C0545 PH OFFSET 0 0 {1 inc.} 65535 Phase offset, function block
DFOUT
z Displacing the zero pulse
generated via DFOUT-SYN-RDY
by up to 360 °
z 1 rev. = 65535 inc (360 °)
