Troubleshooting and fault elimination
Resetting error messages
9
9.5
9.5-1
EDSVF9333V EN 3.0-06/2005
9.5 Resetting error messages
After you have eliminated the cause of a TRIP fault message, you must reset
the fault message with the command ”TRIP reset”. Only then the drive
restarts.
Note!
A TRIP fault message can have several causes. Only if all causes
of the TRIP have been eliminated, the TRIP reset can be executed.
ƒ Keypad XT: press . Then press , to enable the controller.
ƒ Fieldbus module: set C0043 = 0
ƒ Control word: C0135
ƒ Terminal: X5/E5 = HIGH
ƒ Control word via AIF
ƒ Control word via system bus (CAN)
Mains switching always executes TRIP reset.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0043 Trip reset 0
0 no/trip reset Reset actual error
1 trip active There is an error TRIP
Eliminate the cause of TRIP
fault message
TRIP reset
