Configuration
Code table
8
8.3

8.3-43
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0715 Function 0
Function selection, function block
TRANS2
See System
Manual
(extension)
0 Rising trans Rising edge 1. LOW-HIGH edge at TRANS2-IN
switches TRANS2-OUT = HIGH
2. After the time has elapsed
(C0716),
TRANS2-OUT switches to LOW
1 Falling trans Falling edge 1. HIGH-LOW edge at TRANS2-IN
switches TRANS2-OUT = HIGH
2. After the time has elapsed
(C0716),
TRANS2-OUT switches to LOW
2 Both trans Both edges 1. LOW-HIGH or HIGH-LOW edge
at TRANS2-IN switches
TRANS2-OUT = HIGH
2. After the time has elapsed
(C0716),
TRANS2-OUT switches to LOW
C0716 Pulse T 0.001 0.001 {0.001
s}
60.000 Pulse duration, function block
TRANS2
z After the time has elapsed,
TRANS2-OUT switches to LOW
C0718

CFG: IN 1000 FIXED0  Selection list 2 Configuration of digital input
signal, function block TRANS2
C0719 DIS: IN 0 1 Function block TRANS2
z Display of the signal linked in
C0718
C0720 Function 2
Function selection, function block
DIGDEL1
See System
Manual
(extension)
0 On delay On delay 1. LOW-HIGH edge at
DIGDEL1-IN starts a timing
element
2. After the time has elapsed
(C0721), DIGDEL1-OUT
switches to HIGH
1 Off delay Off delay 1. LOW-HIGH edge at
DIGDEL1-IN starts a timing
element and sets
DIGDEL1-OUT = HIGH
2. After the time has elapsed
(C0721), DIGDEL1-OUT
switches to LOW
2 ON/OFF delay On/off delay 1. LOW-HIGH or HIGH-LOW edge
at DIGDEL1-IN starts a timing
element
2. After the time has elapsed
(C0721),
DIGDEL1-OUT = DIGDEL1-IN
C0721 Delay T 1.000 0.001 {0.001
s}
60.000 Delay time, function block
DIGDEL1
C0723

CFG: IN 1000 FIXED0  Selection list 2 Configuration of digital input
signal, function block DIGDEL1
C0724 DIS: IN 0 1 Function block DIGDEL1
z Display of the signal linked in
C0723
