Configuration
Code table
8
8.3
8.3-20
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0234 damp value 20 -100 {1 %} 100 Influence of the oscillation
damping, function block MCTRL
z Minimising a tendency to
oscillation of the drive
z Influences the tendency to
oscillation of the drive
z When C0025 >1 and
C0006 = 1, C0234 is set to 0
8.2-25
8.2-48
C0235 damping 5 1 {1 ms} 600 Filter time of the oscillation
damping, function block MCTRL
z Filter time for the internal
signal for oscillation damping
8.2-25
8.2-48
C0236 damp limit 0.2 0.0 {0.1 Hz} 20.0 Limit value of oscillation
damping, function block MCTRL
z Limit value for the internal
signal of oscillation damping
C0241 Cmp-RFG-I=0 1.00 0.00 {0.01 %} 100.00 Speed threshold in [%] for the
digital output NSET-controller
enable-I=0, function block NSET
z The analog signals NSET-NOUT
(without arithmetic and
limiting functions) and
NSET-controller enable-I are
compared
z NSET-controller
enable-I=0=HIGH:the
differential signal between
NSET-NOUT and
NSET-controller enable-I falls
below the value in C0241
z C0241 = 100 %: n
max
See System
Manual
(extension)
C0244 BRK1 M set 0.00 0.00 {0.01 %} 100.00 Holding torque, function block
BRK1
z C0244 = 100 % = C0057
See System
Manual
(extension)
C0250 FCODE 1 Bit 0 0 1 Free control code FCODE250
C0252 Angle offset 0 -245760000 {1 inc.} 245760000 Phase offset for master frequency
processing, function block DFSET
z Fixed phase offset for digital
frequency configuration
z 1 rev. = 65536 inc
8.2-18
C0253 Angle n-trim Æ -32767 {1 inc.} 32767 Speed-dependent phase
trimming for the master
frequency processing, f unction
block DFSET
Æ depending on C0005, C0025,
C0490
z Change of C0005, C0025 or
C0490 resets C0253 to the
corresponding Lenze setting
z 1 rev. = 65536 inc
z Value in C0253 is reached at
15000 rpm
