Lexmark MS725 Service Manual

Error code Description Action
230.44 Paper fed from tray 4 cleared the sensor (duplex
path) earlier than expected.
See
“Sensor (duplex path) early‑leaving jam
service check” on page 108.
230.45 Paper fed from tray 4 never cleared the sensor
(duplex path).
See
“Sensor (duplex path) late-leaving jam
service check” on page 108.
230.52 Paper fed from tray 5 was detected earlier than
expected at the sensor (duplex path).
See
“Sensor (duplex path) early-arriving jam
service check” on page 105.
230.53 Paper fed from tray 5 never reached the sensor
(duplex path).
See
“Sensor (duplex path) late-arriving jam
service check” on page 106.
230.54 Paper fed from tray 5 cleared the sensor (duplex
path) earlier than expected.
See
“Sensor (duplex path) early‑leaving jam
service check” on page 108.
230.55 Paper fed from tray 5 never cleared the sensor
(duplex path).
See
“Sensor (duplex path) late-leaving jam
service check” on page 108.
230.91 Paper remains detected at the sensor (duplex
path) after the printer is turned on.
See
“Sensor (duplex path) static jam service
check” on page 110.
Sensor (duplex path) early-arriving jam service check
Action Yes No
Step 1
Check the duplex paper path for jammed paper and obstructions.
Note: Make sure that all paper fragments are removed.
Is the duplex paper path free of jammed paper and obstructions?
Go to step 3. Go to step 2.
Step 2
Remove the jammed paper and obstructions.
Does the problem remain?
Go to step 3. The problem is
solved.
Step 3
a Remove the duplex/MPF tray. See “Duplex/MPF tray removal”
on page 434.
b Enter the Diagnostics menu, and then navigate to:
Printer diagnostics and adjustments > Sensor tests
c Find the sensor (Duplex path).
Does the sensor status change while toggling the sensor?
Go to step 6. Go to step 4.
Step 4
a Remove the right cover. See “Right cover removal” on
page 420.
b Check the sensor cable J27 on the controller board for proper
connection.
Is the cable properly connected?
Go to step 6. Go to step 5.
4064
Diagnostics and troubleshooting
105

Lexmark MS725 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	- ppm
Display	LCD
Product color	Black, White
Display diagonal	2.4 \
Market positioning	-
Paper tray media types	Card stock, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Folio (media size), Oficio (media size), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Security features	IPSec, SNMPv3, 802.1x Authentication: MD5, MSCHAPv2, LEAP, PEAP, TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Maximum internal memory	4608 MB
Sound pressure level (printing)	56 dB
Sound pressure level (duplex printing)	55 dB
Power consumption (off)	0.2 W
Power consumption (sleep)	1.3 W
Power consumption (printing)	720 W
Energy Star Typical Electricity Consumption (TEC)	1.28 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	IBM AIX 6.1, IBM AIX 7.1, Novell Open Enterprise Server, Solaris 10 SPARC, Solaris 11
Server operating systems supported	Windows 2000 Server, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	5000 - 75000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3, XML, XPS
Total input capacity	650 sheets
Total output capacity	550 sheets
Maximum input capacity	4400 sheets
Maximum number of input trays	6
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	650.2 mm
Package width	551.2 mm
Package height	563.9 mm
Package weight	30980 g

Weight and Dimensions

Depth	510.5 mm
Width	428 mm
Height	444.5 mm
