Lexmark MS725 Service Manual

Action Yes No
Step 12
Reinstall or replace the motor. See
“Motor (staple finisher paddle)
removal” on page 592.
Does the problem remain?
Go to step 13. The problem is
solved.
Step 13
Make sure that the controller board of the aected optional bin is
properly installed. Reseat all the cables on the controller board.
Does the problem remain?
Go to step 14. The problem is
solved.
Step 14
Check the aected controller board and its connector pins for
damage.
Are the bin controller board and its connectors free of damage?
Contact the next
level of support.
Go to step 15.
Step 15
Replace the bin controller board. See
“Staple finisher controller
board removal” on page 590.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Staple finisher diverter jam service check
Action Yes No
Step 1
Make sure that all the optional bins are properly installed.
Does the problem remain?
Go to step 2. The problem is
solved.
Step 2
Open all optional bin doors, and then check the paper path and
bins for paper fragments and partially fed paper.
Is the paper path free of paper fragments and partially fed paper?
Go to step 4. Go to step 3.
Step 3
Remove the paper fragments and partially fed paper.
Does the problem remain?
Go to step 4. The problem is
solved.
Step 4
Clear the optional bin paper path rollers of any dirt and
contamination.
Does the problem remain?
Go to step 5. The problem is
solved.
4064
Diagnostics and troubleshooting
244
