Lexmark MS725 Service Manual

Action Yes No
Step 14
Perform a print test again, and then observe if the motor
(2100‑sheet tray transport) is running.
Does the motor run?
Go step 17. Go to step 15.
Step 15
Reseat the cable on the motor and on the optional tray controller
board.
Does the problem remain?
Go to step 16. The problem is
solved.
Step 16
Replace the motor. See
“Motor (2100-sheet tray transport)
removal” on page 478.
Does the problem remain?
Go to step 17. The problem is
solved.
Step 17
Check the optional tray controller board and its connector pins for
damage.
Are the tray controller board and its connectors free of damage?
Contact the next
level of support.
The problem is
solved.
Step 18
Replace the optional tray controller board. See
“2100-sheet tray
controller board removal” on page 483.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
243 paper jams
243 paper jam messages
Error code Description Action
243.36 Paper fed from tray 3 was picked but it never
reached the sensor (tray 2 pass‑through).
See
“Tray 3 pick jam service check” on
page 158.
243.41 Paper remains detected at the sensor (tray 3
pass‑through) although the printer is idle. Tray 4
is the paper source.
See
“Sensor (tray 3 pass‑through) static jam
service check” on page 156.
243.43 Paper fed from tray 4 never reached the sensor
(tray 3 pass‑through).
See
“Sensor (tray 3 pass‑through) late‑arriving
or late-leaving jam service check” on page
161.
243.45 Paper fed from tray 4 cleared the sensor (tray 3
pass‑through) later than expected.
243.47 Paper fed from tray 4 never cleared the sensor
(tray 3 pass‑through).
4064
Diagnostics and troubleshooting
154

Lexmark MS725 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	- ppm
Display	LCD
Product color	Black, White
Display diagonal	2.4 \
Market positioning	-
Paper tray media types	Card stock, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Folio (media size), Oficio (media size), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Security features	IPSec, SNMPv3, 802.1x Authentication: MD5, MSCHAPv2, LEAP, PEAP, TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Maximum internal memory	4608 MB
Sound pressure level (printing)	56 dB
Sound pressure level (duplex printing)	55 dB
Power consumption (off)	0.2 W
Power consumption (sleep)	1.3 W
Power consumption (printing)	720 W
Energy Star Typical Electricity Consumption (TEC)	1.28 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	IBM AIX 6.1, IBM AIX 7.1, Novell Open Enterprise Server, Solaris 10 SPARC, Solaris 11
Server operating systems supported	Windows 2000 Server, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	5000 - 75000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3, XML, XPS
Total input capacity	650 sheets
Total output capacity	550 sheets
Maximum input capacity	4400 sheets
Maximum number of input trays	6
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	650.2 mm
Package width	551.2 mm
Package height	563.9 mm
Package weight	30980 g

Weight and Dimensions

Depth	510.5 mm
Width	428 mm
Height	444.5 mm
